Technical Specifications
| Bearing Unit No | Shaft Dia | Dimensions(mm) | Bolt Used | |||||||||||
| d | ||||||||||||||
| (mm) | H | J | A1 | A2 | A | N | L | A0 | B | S | C1 | 2s | ||
| KFL08 | 8 | 48 | 36 | 4 | 4 | 8.5 | 5 | 27 | 12 | 11 | 3 | 4 | 12 | M5 |
| KFL000 | 10 | 60 | 45 | 5.5 | 5.5 | 11.5 | 7 | 36 | 15.5 | 14 | 4 | 6 | 22 | M6 |
| KFL001 | 12 | 63 | 48 | 5.5 | 5.5 | 11.5 | 7 | 38 | 16 | 14.5 | 4 | 6.5 | 22 | M6 |
| KFL002 | 15 | 67 | 53 | 6.5 | 6.5 | 13 | 7 | 42 | 18.5 | 16.5 | 4.5 | 5 | 24 | M6 |
| KFL003 | 17 | 71 | 56 | 7 | 7 | 14 | 7 | 46 | 19.5 | 17.5 | 5 | 6 | 26 | M6 |
| KFL004 | 20 | 90 | 71 | 8 | 8 | 16 | 10 | 55 | 23 | 21 | 6 | 7.5 | 31 | M8 |
| KFL005 | 25 | 95 | 75 | 8 | 8 | 16 | 10 | 60 | 24.5 | 22.5 | 6 | 7 | 32 | M8 |
| KFL006 | 30 | 112 | 85 | 9 | 9 | 18 | 13 | 70 | 27 | 24.5 | 6.5 | 6.5 | 34 | M10 |
| KFL007 | 35 | 122 | 96 | 11 | 11 | 21 | 14 | 80 | 33 | 30 | 8 | 8 | 38 | M12 |
LEAVE US A MESSAGE
If you have any questions, please fill out the form to contact us, and our customer service will reply to you within 24 hours!
|
Suffixes |
|
|
Sealing Types |
|
|
2Z |
Metal shield (non-contact sealing) on both sides |
|
2RS |
One lip rubber metal seal on both sides |
|
2RS1 |
One lip rubber metal seal on both sides |
|
2S |
One lip rubber metal seal (on both sides) |
|
2F |
One lip rubber metal seal + flinger, on both sides |
|
2T |
Three lip seal on both sides |
|
T |
Outer ring with stopping pin |
|
2TC |
Three lip seal on both sides+ metal cover |
|
2TB |
Three lip seal + metal shield, on both sides |
|
TDT |
Three lip seal at one side, double three lip seal on the other side |
|
FS |
Sealing with one lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBS |
Sealing with three lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBT |
Sealing with three lip seal and a protective metal ring at one side and three lip seal on the other side |
|
2P |
Five lip seal on both sides |
|
2PB |
Five lip seal and metal shield, on both sides |
|
2PC |
Five lip seal on both sides + metal cover |
|
P |
Triple lip seal on one side, cylindrical surface of outer ring |
|
PP |
Triple lip seal, cylindrical surface of outer ring |
|
PB |
Triple lip seal on one side, spherical surface of outer ring |
|
PPB |
Triple lip seal, spherical surface of outer ring |
|
RR |
One lip seal cylindrical surface of outer ring |
|
RRB |
One lip seal spherical surface of outer ring |
|
KPP |
Triple lip seal cylindrical surface of outer ring |
|
KPPB |
Triple lip seal spherical surface of outer ring |
|
KR |
One lip seal on one side, cylindrical surface of outer ring |
|
KRR |
One lip seal, cylindrical surface of outer ring |
|
KRB |
One lip seal on one side, spherical surface |
|
KRRB |
One lip seal, spherical surface |
|
KRP |
One lip seal on one side and on the other side is triple lip seal |
