Technical Specifications
| Bearing No. | Shaft diameter (d) | Dimension (mm) | Bolt specification | Bearing No. | Housing No. | Weight(kg) | |||||||||
| (min.) | (mm) | H | J | L | A2 | A1 | A | E | N | S | |||||
| SAFL 201 201-8 202 202-10 203 203-11 | 1/2 5/8 11/16 | 12 15 17 | 99 | 76,5 | 57 | 15 | 11 | 24,5 | 37,1 | 12 | 6,5 | M10 | SA 201 201-8 202 202-10 203 203-11 | FL203 | 0.38 |
| SAFL204-12 204 | 3/4 | 20 | 113 | 90 | 60 | 15 | 11 | 25,5 | 38,4 | 12 | 7,5 | M10 | SA 204-12 204 | FL204 | 0.39 |
| SAFL205-14 205-15 205 205-16 | 7/8 15/16 1 | 25 | 130 | 99 | 68 | 16 | 13 | 27 | 39,4 | 16 | 7,5 | M14 | SA 205-14 205-15 205 205-16 | FL205 | 0.58 |
| SAFL206-18 206 206-19 206-20 | 1-1/8 1-3/16 1-1/4 | 30 | 148 | 117 | 80 | 18 | 13 | 31 | 44,7 | 16 | 9 | M14 | SA206-18 206 206-19 206-20 | FL206 | 0.84 |
| SAFL207-20 207-21 207-22 207 207-23 | 1-1/4 1-5/16 1-3/8 1-7/16 | 35 | 161 | 130 | 90 | 19 | 14 | 34 | 48,4 | 16 | 9,5 | M14 | SA207-20 207-21 207-22 207 207-23 | FL207 | 1.36 |
| SAFL208-24 208-25 208 | 1-1/2 1-9/16 | 40 | 175 | 144 | 100 | 21 | 14 | 36 | 53,7 | 16 | 11 | M14 | SA208-24 208-25 208 | FL208 | 1.38 |
| SAFL209-26 209-27 209-28 209 | 1-5/8 1-11/16 1-3/4 | 45 | 188 | 148 | 108 | 22 | 16 | 38 | 54,7 | 19 | 11 | M16 | SA209-26 209-27 209-28 209 | FL209 | 1.86 |
| SAFL210-30 210-31 210 210-32 | 1-7/8 1-15/16 2 | 50 | 197 | 157 | 115 | 22 | 16 | 40 | 54,7 | 19 | 11 | M16 | SA210-30 210-31 210 210-32 | FL210 | 2.17 |
| SAFL211-32 211-34 211 211-35 | 2 2-1/8 2-3/16 | 55 | 224 | 184 | 130 | 25 | 18 | 43 | 61,4 | 19 | 12 | M16 | SA211-32 211-34 211 211-35 | FL211 | 2.81 |
| SAFL212-36 212 212-38 212-39 | 2-1/4 2-3/8 2-7/16 | 60 | 250 | 202 | 140 | 29 | 18 | 48 | 66,3 | 23 | 12 | M20 | SA212-36 212 212-38 212-39 | FL212 | 3.66 |
LEAVE US A MESSAGE
If you have any questions, please fill out the form to contact us, and our customer service will reply to you within 24 hours!
|
Suffixes |
|
|
Sealing Types |
|
|
2Z |
Metal shield (non-contact sealing) on both sides |
|
2RS |
One lip rubber metal seal on both sides |
|
2RS1 |
One lip rubber metal seal on both sides |
|
2S |
One lip rubber metal seal (on both sides) |
|
2F |
One lip rubber metal seal + flinger, on both sides |
|
2T |
Three lip seal on both sides |
|
T |
Outer ring with stopping pin |
|
2TC |
Three lip seal on both sides+ metal cover |
|
2TB |
Three lip seal + metal shield, on both sides |
|
TDT |
Three lip seal at one side, double three lip seal on the other side |
|
FS |
Sealing with one lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBS |
Sealing with three lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBT |
Sealing with three lip seal and a protective metal ring at one side and three lip seal on the other side |
|
2P |
Five lip seal on both sides |
|
2PB |
Five lip seal and metal shield, on both sides |
|
2PC |
Five lip seal on both sides + metal cover |
|
P |
Triple lip seal on one side, cylindrical surface of outer ring |
|
PP |
Triple lip seal, cylindrical surface of outer ring |
|
PB |
Triple lip seal on one side, spherical surface of outer ring |
|
PPB |
Triple lip seal, spherical surface of outer ring |
|
RR |
One lip seal cylindrical surface of outer ring |
|
RRB |
One lip seal spherical surface of outer ring |
|
KPP |
Triple lip seal cylindrical surface of outer ring |
|
KPPB |
Triple lip seal spherical surface of outer ring |
|
KR |
One lip seal on one side, cylindrical surface of outer ring |
|
KRR |
One lip seal, cylindrical surface of outer ring |
|
KRB |
One lip seal on one side, spherical surface |
|
KRRB |
One lip seal, spherical surface |
|
KRP |
One lip seal on one side and on the other side is triple lip seal |
