Technical Specifications
| Bearing No. | Shaft diameter(d) | Dimension(mm) | BearingNo. | Housing No. | Weight (kg) | |||||
| (in.) | (mm) | L | A | S | B | r | ||||
| UCC201S 201-8S 202S 202-10S 203S 203-11S | 1/2 5/8 11/16 | 12 15 17 | 67 | 20 | 11.5 | 27.4 | 1.5 | UC201S 201-8S 202S 202-10S 203S. 203-11S | C203 | 0.43 0.42 0.41 |
| UCC201 201-8 202 202-10 203 203-11 204-12 204 | 1/2 5/8 11/16 3/4 | 12 15 17 20 | 72 | 20 | 12.7 | 31 | 1.5 | UC201 201-8 202 202-10 203 203-11 204-12 204 | C204 | 0.53 0.51 0.50 0.48 |
| UCC205-14 205-15 205 205-16 | 7/8 15/16 1 | 25 | 80 | 22 | 14.3 | 34 | 1.5 | UC 205-14 205-15 205 205-16 | C205 | 0.64 |
| UCC206-18 206 206-19 206-20 | 1-1/8 1-3/16 1-1/4 | 30 | 85 | 27 | 15.9 | 38.1 | 1.5 | UC 206-18 206 206-19 206-20 | C206 | 0.79 |
| UCC207-20 207-21 207-22 207 207-23 | 1-1/4 1-5/16 1-3/8 1-7/16 | 35 | 90 | 28 | 17.5 | 42.9 | 1.5 | UC 207-20 207-21 207-22 207 207-23 | C207 | 0.92 |
| UCC208-24 208-25 208 | 1-1/2 1-9/16 | 40 | 100 | 30 | 19 | 49.2 | 1.5 | UC 208-24 208-25 208 | C208 | 1.20 |
| UCC209-26 209-27 209-28 209 | 1-5/8 1-11/16 1-3/4 | 45 | 110 | 31 | 19 | 49.2 | 2 | UC 209-26 209-27 209-28 209 | C209 | 1.47 |
| UCC210-30 210-31 210 210-32 | 1-7/8 1-15/16 2 | 50 | 120 | 33 | 19 | 51.6 | 2 | UC 210-30 210-31 210 210-32 | C210 | 1.90 |
| UCC211-32 211-34 211 211-35 | 2 2-1/8 2-3/16 | 55 | 125 | 35 | 22.2 | 55.6 | 2 | UC 211-32 211-34 211 211-35 | C211 | 2.12 |
| UCC212-36 212 212-38 212-39 | 2-1/4 2-3/8 2-7/16 | 60 | 130 | 38 | 25.4 | 65.1 | 2 | UC 212-36 212 212-38 212-39 | C212 | 2.51 |
| UCC213-40 213 | 2-1/2 | 65 | 140 | 40 | 25.4 | 65.1 | 2 | UC 213-40 213 | C213 | 2.90 |
| UCC214-44 214 | 2-3/4 | 70 | 150 | 44 | 30.2 | 74.6 | 2.5 | UC214-44 214 | C214 | 3.72 |
| UCC215-47 215 UCC215-48 | 2-15/16 3 | 75 | 160 | 44 | 33.3 | 77.8 | 2.5 | UC215-47 215 UC215-48 | C215 | 4.39 |
| UCC216 | 80 | 170 | 48 | 33.3 | 82.6 | 2.5 | UC216 | C216 | 5.28 | |
LEAVE US A MESSAGE
If you have any questions, please fill out the form to contact us, and our customer service will reply to you within 24 hours!
|
Suffixes |
|
|
Sealing Types |
|
|
2Z |
Metal shield (non-contact sealing) on both sides |
|
2RS |
One lip rubber metal seal on both sides |
|
2RS1 |
One lip rubber metal seal on both sides |
|
2S |
One lip rubber metal seal (on both sides) |
|
2F |
One lip rubber metal seal + flinger, on both sides |
|
2T |
Three lip seal on both sides |
|
T |
Outer ring with stopping pin |
|
2TC |
Three lip seal on both sides+ metal cover |
|
2TB |
Three lip seal + metal shield, on both sides |
|
TDT |
Three lip seal at one side, double three lip seal on the other side |
|
FS |
Sealing with one lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBS |
Sealing with three lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBT |
Sealing with three lip seal and a protective metal ring at one side and three lip seal on the other side |
|
2P |
Five lip seal on both sides |
|
2PB |
Five lip seal and metal shield, on both sides |
|
2PC |
Five lip seal on both sides + metal cover |
|
P |
Triple lip seal on one side, cylindrical surface of outer ring |
|
PP |
Triple lip seal, cylindrical surface of outer ring |
|
PB |
Triple lip seal on one side, spherical surface of outer ring |
|
PPB |
Triple lip seal, spherical surface of outer ring |
|
RR |
One lip seal cylindrical surface of outer ring |
|
RRB |
One lip seal spherical surface of outer ring |
|
KPP |
Triple lip seal cylindrical surface of outer ring |
|
KPPB |
Triple lip seal spherical surface of outer ring |
|
KR |
One lip seal on one side, cylindrical surface of outer ring |
|
KRR |
One lip seal, cylindrical surface of outer ring |
|
KRB |
One lip seal on one side, spherical surface |
|
KRRB |
One lip seal, spherical surface |
|
KRP |
One lip seal on one side and on the other side is triple lip seal |
