Technical Specifications
| Bearing No. | Shaft diameter (d) | Dimension(mm) | Bearing No. | Housing No. | weight (kg) | |||||||||
| (min.) | (mm) | H0 | L | C | H | A | F | M | B | S | ||||
| UCHA201 201-8 202 202-10 203 203-11 204-12 204 | 1/2 5/8 11/16 3/4 | 12 15 17 20 | 96 | 64 | 64 | 40 | 19 | G3/4 | 31 | 12,7 | UC 201 201-8 202 202-10 203 203-11 204-12 204 | HA204 | 0,73 | |
| UCHA205-14 205-15 205 205-16 | 7/8 15/16 1 | 25 | 103 | 78 | 64 | 40 | 19 | G3/4 | 34 | 14,3 | UC205-14 205-15 205 205-16 | HA205 | 0,88 | |
| UCHA206-18 206 206-19 206-20 | 1-1/8 1-3/16 1-1/4 | 30 | 103 | 78 | 64 | 40 | 19 | G3/4 | 38,1 | 15,9 | UC206-18 206 206-19 206-20 | HA206 | 1,0 | |
| UCHA207-20 207-21 207-22 207 207-23 | 1-1/14 1-5/16 1-3/8 1-7/16 | 35 | 116 | 92 | 70 | 40 | 19 | G3/4 | 42,9 | 17,5 | UC207-20 207-21 207-22 207 207-23 | HA207 | 1,2 | |
| UCHA208-24 208-25 208 | 1-1/2 1-9/16 | 40 | 121 | 96 | 2 | 73 | 40 | 19 | G3/4 | 49,2 | 19 | UC208-24 208-25 208 | HA208 | 1,3 |
| UCHA209-26 209-27 209-28 209 | 1-5/8 1-11/16 1-3/4 | 45 | 136 | 108 | 5 | 82 | 48 | 21 | G1 | 49.2 | 19 | UC209-26 209-27 209-28 209 | HA209 | 1,8 |
| UCHA210-30 210-31 210 210-32 | 1-7/8 1-15/16 2 | 50 | 140,5 | 115 | 5 | 83 | 48 | 21 | G1 | 51,6 | 19 | UC210-30 210-31 210 210-32 | HA210 | 2,1 |
| UCHA211-32 211-34 211 211-35 | 2 2-1/8 2-3/16 | 55 | 150 | 126 | 7 | 87 | 60 | 24 | G1-1/4 | 55,6 | 22,2 | UC211-32 211-34 211 211-35 | HA211 | 2,8 |
| UCHA212-36 212 212-38 212-39 | 2-1/4 2-3/8 2-7/16 | 60 | 173 | 142 | 9 | 102 | 60 | 28 | G1-1/4 | 65,1 | 25,4 | UC212-36 212 212-38 212-39 | HA212 | 3,9 |
| UCHA213-40 213 | 2-1/2 | 65 | 200 | 166 | 9,5 | 117 | 70 | 32 | G1-1/2 | 65,1 | 25,4 | UC213-40 213 | HA213 | 5,9 |
| UCHA214-44 214 | 2-3/4 | 70 | 200 | 166 | 9,5 | 117 | 70 | 32 | G1-1/2 | 74,6 | 30,2 | UC214-44 214 | HA214 | 5,9 |
| UCHA215-47 215 215-48 | 2-15/16 3 | 75 | 200 | 166 | 9,5 | 117 | 70 | 32 | G1-1/2 | 77,8 | 33,2 | UC215-47 215 215-48 | HA215 | 5,9 |
LEAVE US A MESSAGE
If you have any questions, please fill out the form to contact us, and our customer service will reply to you within 24 hours!
|
Suffixes |
|
|
Sealing Types |
|
|
2Z |
Metal shield (non-contact sealing) on both sides |
|
2RS |
One lip rubber metal seal on both sides |
|
2RS1 |
One lip rubber metal seal on both sides |
|
2S |
One lip rubber metal seal (on both sides) |
|
2F |
One lip rubber metal seal + flinger, on both sides |
|
2T |
Three lip seal on both sides |
|
T |
Outer ring with stopping pin |
|
2TC |
Three lip seal on both sides+ metal cover |
|
2TB |
Three lip seal + metal shield, on both sides |
|
TDT |
Three lip seal at one side, double three lip seal on the other side |
|
FS |
Sealing with one lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBS |
Sealing with three lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBT |
Sealing with three lip seal and a protective metal ring at one side and three lip seal on the other side |
|
2P |
Five lip seal on both sides |
|
2PB |
Five lip seal and metal shield, on both sides |
|
2PC |
Five lip seal on both sides + metal cover |
|
P |
Triple lip seal on one side, cylindrical surface of outer ring |
|
PP |
Triple lip seal, cylindrical surface of outer ring |
|
PB |
Triple lip seal on one side, spherical surface of outer ring |
|
PPB |
Triple lip seal, spherical surface of outer ring |
|
RR |
One lip seal cylindrical surface of outer ring |
|
RRB |
One lip seal spherical surface of outer ring |
|
KPP |
Triple lip seal cylindrical surface of outer ring |
|
KPPB |
Triple lip seal spherical surface of outer ring |
|
KR |
One lip seal on one side, cylindrical surface of outer ring |
|
KRR |
One lip seal, cylindrical surface of outer ring |
|
KRB |
One lip seal on one side, spherical surface |
|
KRRB |
One lip seal, spherical surface |
|
KRP |
One lip seal on one side and on the other side is triple lip seal |
