Technical Specifications
| Bearing No. | Shaft diameter(d) | Dimension (mm) | Bolt specification | Bearing No. | Housing No. | weight(kg) | |||||||||
| (min.) | (mm) | H | L | J | A | H0 | H1 | S | B | F | |||||
| UCPA201 201-8 202 202-10 203 203-11 204-12 204 | 1/2 5/8 11/16 3/4 | 12 15 17 20 | 30,2 | 76 | 52 | 40 | 62 | 11 | 12,7 | 31 | 13 | M10 | UC 201 201-8 202 202-10 203 203-11 204-12 204 | PA204 | 0,63 |
| UCPA205-14 205-15 205 205-16 | 7/8 15/16 1 | 25 | 36,5 | 84 | 56 | 38 | 72 | 12 | 14,3 | 34 | 15 | M10 | UC205-14 205-15 205 205-16 | PA205 | 0,8 |
| UCPA206-18 206 206-19 206-20 | 1-1/8 1-3/16 1-1/4 | 30 | 42,9 | 94 | 66 | 48 | 84 | 13 | 15,9 | 38,1 | 18 | M12 | UC206-18 206 206-19 206-20 | PA206 | 1,2 |
| UCPA207-20 207-21 207-22 207 207-23 | 1-1/14 1-5/16 1-3/8 1-7/16 | 35 | 47,6 | 110 | 80 | 48 | 95 | 13 | 17,5 | 42,9 | 20 | M12 | UC207-20 207-21 207-22 207 207-23 | PA207 | 1,7 |
| UCPA208-24 208-25 208 | 1-1/2 1-9/16 | 40 | 49,2 | 116 | 84 | 54 | 100 | 13 | 19 | 49,2 | 20 | M12 | UC208-24 208-25 208 | PA208 | 2,0 |
| UCPA209-26 209-27 209-28 209 | 1-5/8 1-11/16 1-3/4 | 45 | 54,2 | 120 | 90 | 60 | 108 | 13 | 19 | 49,2 | 25 | M12 | UC209-26 209-27 209-28 209 | PA209 | 2,2 |
| UCPA210-30 210-31 210 210-32 | 1-7/8 1-15/16 2 | 50 | 57,2 | 130 | 94 | 60 | 116 | 14 | 19 | 51,6 | 25 | M16 | UC210-30 210-31 210 210-32 | PA210 | 2,8 |
| UCPA211-32 211-34 211 211-35 | 2 2-1/8 2-3/16 | 55 | 63,5 | 140 | 104 | 66 | 125 | 14 | 22,2 | 55,6 | 25 | M16 | UC211-32 211-34 211 211-35 | PA211 | 3,0 |
| UCPA212-36 212 212-38 212-39 | 2-1/4 2-3/8 2-7/16 | 60 | 69,9 | 150 | 114 | 68 | 138 | 15 | 25,4 | 65,1 | 25 | M16 | UC212-36 212 212-38 212-39 | PA212 | 4,24 |
| UCPA213-40 213 | 2-1/2 | 65 | 76,2 | 160 | 124 | 70 | 150 | 15 | 25,4 | 65,1 | 25 | M16 | UC213-40 213 | PA213 | — |
LEAVE US A MESSAGE
If you have any questions, please fill out the form to contact us, and our customer service will reply to you within 24 hours!
|
Suffixes |
|
|
Sealing Types |
|
|
2Z |
Metal shield (non-contact sealing) on both sides |
|
2RS |
One lip rubber metal seal on both sides |
|
2RS1 |
One lip rubber metal seal on both sides |
|
2S |
One lip rubber metal seal (on both sides) |
|
2F |
One lip rubber metal seal + flinger, on both sides |
|
2T |
Three lip seal on both sides |
|
T |
Outer ring with stopping pin |
|
2TC |
Three lip seal on both sides+ metal cover |
|
2TB |
Three lip seal + metal shield, on both sides |
|
TDT |
Three lip seal at one side, double three lip seal on the other side |
|
FS |
Sealing with one lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBS |
Sealing with three lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBT |
Sealing with three lip seal and a protective metal ring at one side and three lip seal on the other side |
|
2P |
Five lip seal on both sides |
|
2PB |
Five lip seal and metal shield, on both sides |
|
2PC |
Five lip seal on both sides + metal cover |
|
P |
Triple lip seal on one side, cylindrical surface of outer ring |
|
PP |
Triple lip seal, cylindrical surface of outer ring |
|
PB |
Triple lip seal on one side, spherical surface of outer ring |
|
PPB |
Triple lip seal, spherical surface of outer ring |
|
RR |
One lip seal cylindrical surface of outer ring |
|
RRB |
One lip seal spherical surface of outer ring |
|
KPP |
Triple lip seal cylindrical surface of outer ring |
|
KPPB |
Triple lip seal spherical surface of outer ring |
|
KR |
One lip seal on one side, cylindrical surface of outer ring |
|
KRR |
One lip seal, cylindrical surface of outer ring |
|
KRB |
One lip seal on one side, spherical surface |
|
KRRB |
One lip seal, spherical surface |
|
KRP |
One lip seal on one side and on the other side is triple lip seal |
