Technical Specifications
| Shaft diameter(d) | Bearing No. | Dimension(mm) | Bolt specification | Bearing No. | Housing No. | Sleeve No. | Weight(kg) | ||||||||||
| min | mm | H | L | J | A | N | N1 | H1 | H0 | S1 | B1 | ||||||
| 3/4 | 25 | UKP305+HE2305 305+H2305 | 45 | 175 | 132 | 45 | 17 | 20 | 15 | 85 | 21.5 | 35 | M14 | UK305 | P305 | HE2305 H2305 | 1.51 |
| 7/8 15/16 1 | 30 | UKP306+HS2306 306+HA2306 306+H2306 306+HE2306 | 50 | 180 | 140 | 50 | 17 | 20 | 18 | 95 | 23 | 38 | M14 | UK306 | P306 | HS2306 HA2306 H2306 HE2306 | 1.85 |
| 1-1/8 1-3/16 | 35 | UKP307+HS2307 307+H2307 307+HA2307 | 56 | 210 | 160 | 56 | 17 | 25 | 20 | 106 | 25,5 | 43 | M14 | UK307 | P307 | HS2307 H2307 HA2307 | 3.02 |
| 1-1/4 1-3/8 | 40 | UKP308+HE2308 308+HS2308 308+H2308 | 60 | 220 | 170 | 60 | 17 | 27 | 22 | 116 | 27,5 | 46 | M14 | UK308 | P308 | HE2308 HS2308 H2308 | 3.38 |
| 1-7/16 1-1/2 | 45 | UKP309+HA2309 309+HE2309 309+H2309 | 67 | 245 | 190 | 67 | 20 | 30 | 24 | 129 | 30 | 50 | M16 | UK309 | P309 | HA2309 HE2309 H2309 | 4.55 |
| 1-5/8 1-11/16 1-3/4 | 50 | UKP310+HS2310 310+HA2310 310+HE2310 310+H2310 | 75 | 275 | 212 | 75 | 20 | 35 | 27 | 143 | 32 | 55 | M16 | UK310 | P310 | HS2310 HA2310 HE2310 H2310 | 6.14 |
| 1-7/8 1-15/16 2 | 55 | UKP311HS2+311 311+HA2311 311+H2311 311+HE2311 | 80 | 310 | 236 | 80 | 20 | 38 | 30 | 154 | 33.5 | 59 | M16 | UK311 | P311 | HS2311 HA2311 H2311 HE2311 | 7.67 |
| 2-1/8 | 60 | UKP312+HS2312 312+H2312 | 85 | 330 | 250 | 85 | 25 | 38 | 32 | 165 | 36.5 | 62 | M20 | UK312 | P312 | HS2312 H2312 | 9.2 |
| 2-3/16 2-1/4 2-3/8 | 65 | UKP313+HA2313 313+HE2313 313+H2313 313+HS2313 | 90 | 340 | 260 | 90 | 25 | 38 | 33 | 176 | 38,5 | 65 | M20 | UK313 | P313 | HA2313 HE2313 H2313 HS2313 | 11.2 |
| 2-7/16 2-1/2 | 75 | UKP315+HA2315 315+HE2315 315+H2315 | 100 | 380 | 290 | 100 | 27 | 40 | 35 | 198 | 42,5 | 73 | M22 | UK315 | P315 | HA2315 HE2315 H2315 | 16.2 |
| 2-11/16 2-3/4 | 80 | UKP316+HA2316 316+HE2316 316+H2316 | 106 | 400 | 300 | 110 | 27 | 40 | 40 | 210 | 44.5 | 78 | M22 | UK316 | P316 | HA2316 HE2316 H2316 | 18 |
| 2-15/16 3 | 85 | UKP317HA2317 317+H2317 317HE2317 | 112 | 420 | 320 | 110 | 33 | 45 | 40 | 220 | 48 | 82 | M27 | UK317 | P317 | HA2317 H2317 HE2317 | 20.5 |
| 90 | UKP318+H2318 | 118 | 430 | 330 | 110 | 33 | 45 | 40 | 235 | 48 | 86 | M27 | UK318 | P318 | H2318 | 25.2 | |
| 3-1/4 | 95 | UKP319+HE2319 319+H2319 | 125 | 470 | 360 | 120 | 36 | 50 | 45 | 248 | 52 | 90 | M30 | UK319 | P319 | HS2319 H2319 | 31.6 |
| 3-1/2 | 100 | UKP320+HE2320 320+H2320 | 140 | 490 | 380 | 120 | 36 | 50 | 50 | 275 | 54 | 97 | M30 | UK320 | P320 | HS2320 H2320 | 37.2 |
| 110 | UKP322+H2322 | 150 | 520 | 400 | 140 | 40 | 55 | 55 | 300 | 61 | 105 | M33 | UK322 | P322 | H2322 | 40 | |
| 120 | UKP324+H2324 | 160 | 570 | 450 | 140 | 40 | 55 | 65 | 320 | 65.5 | 112 | M33 | UK324 | P324 | H2324 | 48.5 | |
| 130 | UKP326+H2326 | 180 | 600 | 480 | 140 | 40 | 55 | 75 | 355 | 68 | 121 | M33 | UK326 | P326 | H2326 | 60 | |
| 140 | UKP328+H2328 | 200 | 620 | 500 | 140 | 40 | 55 | 75 | 390 | 59 | 131 | M33 | UK328 | P328 | H2328 | 76.9 | |
LEAVE US A MESSAGE
If you have any questions, please fill out the form to contact us, and our customer service will reply to you within 24 hours!
|
Suffixes |
|
|
Sealing Types |
|
|
2Z |
Metal shield (non-contact sealing) on both sides |
|
2RS |
One lip rubber metal seal on both sides |
|
2RS1 |
One lip rubber metal seal on both sides |
|
2S |
One lip rubber metal seal (on both sides) |
|
2F |
One lip rubber metal seal + flinger, on both sides |
|
2T |
Three lip seal on both sides |
|
T |
Outer ring with stopping pin |
|
2TC |
Three lip seal on both sides+ metal cover |
|
2TB |
Three lip seal + metal shield, on both sides |
|
TDT |
Three lip seal at one side, double three lip seal on the other side |
|
FS |
Sealing with one lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBS |
Sealing with three lip seal and a protective metal ring at one side and one lip seal on the other side |
|
TBT |
Sealing with three lip seal and a protective metal ring at one side and three lip seal on the other side |
|
2P |
Five lip seal on both sides |
|
2PB |
Five lip seal and metal shield, on both sides |
|
2PC |
Five lip seal on both sides + metal cover |
|
P |
Triple lip seal on one side, cylindrical surface of outer ring |
|
PP |
Triple lip seal, cylindrical surface of outer ring |
|
PB |
Triple lip seal on one side, spherical surface of outer ring |
|
PPB |
Triple lip seal, spherical surface of outer ring |
|
RR |
One lip seal cylindrical surface of outer ring |
|
RRB |
One lip seal spherical surface of outer ring |
|
KPP |
Triple lip seal cylindrical surface of outer ring |
|
KPPB |
Triple lip seal spherical surface of outer ring |
|
KR |
One lip seal on one side, cylindrical surface of outer ring |
|
KRR |
One lip seal, cylindrical surface of outer ring |
|
KRB |
One lip seal on one side, spherical surface |
|
KRRB |
One lip seal, spherical surface |
|
KRP |
One lip seal on one side and on the other side is triple lip seal |
